Epiglottis - RF
From WikiLectures
Epiglottis – RF, 0,5x
- Epiglottis (elastic cartilage):
Epiglottis – RF, 2x
- Epiglottis (elastic cartilage):
- 1) TM – tunica mucosa
- a) ED – stratified squamous non-keratinized epithelium (lingual side)
- b) LP – lamina propria
- 2) P – perichondrium
- 3) ECH – elastická chrupavka
Epiglottis – RF, 10x
- Epiglottis (eelastic cartilage):
- 1) P – perichondrium
- 2) ECH – elastická chrupavka
- 3) IGS – lacuna with isogenous group
- 4) CHC – chondrocyte in lacuna
- 5) EVM – elastic fibers in matrix
Epiglottis – RF, 20x
- Epiglottis (elastic cartilage):
- 1) IGS – lacuna with isogenous group
- 2) CHC – chondrocyte in lacuna
- 3) EVM – elastic fibers in matrix
- 4) EV – elastic fibers
