Skeletal muscle - HE

From WikiLectures


Tongue – radix, HE 20x

Jazyk – radix- Tongue – radix, HE 20x.jpeg

Skeletal muscle – longitudinal:

  • JS – syncytium nucleus
  • SV – muscle fibre

Tongue – radix, HE 40x

Jazyk – radix- Tongue – radix, HE 40x.jpeg

Skeletal muscle – longitudinal:

  • JS – syncytium nucleus
  • SV – muscle fibre
  • AP – A band (dark)
  • IP – I band (light)
  • E – endomysium

Tongue – radix, HE 20x (2)

Jazyk - radix- Tongue - radix (transv.), HE 20x.jpeg

Skeletal muscle – transverse:

  • JS – syncytium nucleus
  • SV – muscle fiber
  • E – endomyzium
  • P – perimysium

Tongue – radix, HE 40x (2)

Jazyk - radix- Tongue - radix (transv.), HE 40x.jpeg

Skeletal muscle – transverse:

  • JS – syncytium nucleus
  • SV – muscle fibre
  • E – endomyzium
