Testis - HE

From WikiLectures


Testis, epididymis – HE, 0,3x

Testis-Epididymis, HE 0,3x.jpeg
  • Testis, epididymis:
  • 1) T – testis
  • 2) TA – tunica albuginea
  • 3) EPD – epididymis


Testis, epididymis – HE, 5x

Testis-Epididymis, HE 5x.jpeg
  • Testis, epididymis:
  • 1) T – testis
  • 2) TA – tunica albuginea
  • 3) ISV – interstitial connective tissue
  • 4) EPD – epididymis
  • a) DEF – ductus efferents


Testis, epididymis – HE, 10x

Testis-Epididymis, HE 10x.jpeg
  • Testis, epididymis:
  • 1) ISV – interstitial connective tissue
  • 2) EPD – epididymis
  • a) DEF – ductus efferents
  • b) EK – cuboidal epithelium
  • c) EC – columnar epithelium
  • 2) A – arteries


Testis, epididymis – HE, 20x

Testis-Epididymis, HE 20x.jpeg
  • Testis, epididymis:
  • 1) ISV – interstitial connective tissue
  • 2) TSC – tubuli seminiferri concorti
  • a) SG – spermatogonia
  • b) PS – primary spermatocytes
  • d) SD1 – early spermatid
  • e) SD2 – late spermatid
  • f) SB – Sertoli cells
  • g) MB – myeloid cell
  • h) F – fibroblast

Testis, epididymis – HE, 0,5x

Testis-Epididymis, HE 0,5x.jpeg
  • Epididymis:


  • 1) TA – tunica albuginea
  • 2) EPD – epididymis

Testis, epididymis – HE, 5x

Testis-Epididymis, HE 5x (2).jpeg
  • Epididymis:


  • 1) TA – tunica albuginea
  • 2) DED – ductus epididymidis
  • 3) TSC – tubuli seminiferri concorti



Testis, epididymis – HE, 10x

Testis-Epididymis, HE 10x (2).jpeg
  • Epididymis:



  • 1) TSC – tubuli seminiferri concorti
  • a) ZE – germinal epithelium
  • 2) C – blood vessels
  • 3) ISV – interstitial connective tissue

Testis, epididymis – HE, 40x

Testis-Epididymis, HE 40x.jpeg
  • Epididymis:


  • 1) ISV – interstitial connective tissue

2) TSC – tubuli seminiferri concorti

  • a) SG – spermatogonia
  • b) PS – primary spermatocytes
  • d) SD1 – early spermatid
  • e) SD2 – late spermatid
  • f) SB – Sertoli cells
  • g) MB – myeloid cell
  • h) LB – Leydig cells
  • 3) SB – muscle cell
