Bulbus oculi HE

Modul B

Eye – HE, 0,4x

Eye:

---

Oko/Eye – HE, 20x

Eye:

• 1) R – retina
• 2) CH – choroidea
• a) BM – Bruch's membrane
• b) LSCH – lamina suprachoroidea
• c) PE – pigmented epithelium
• 3) S – sclera

---

Navigace: Nervová tkáň / Nerve tissue
← Preparation n. 50	|	List of Preparations	|	Preparation n. 44 →

Modul A

Oko/Eye – HE, 0,6x

Eye:

• 1) V – eyelid
• 2) NO – nervus opticus
• 3) Č – lens

---

Eye – HE, 5x

Eye:

• 1) A – artefact
• 4) C – cornea
• a) ERP – cornea epithelium (front)
• b) ERZ – cornea epithelium (back)
• 5) SCP – sclerocorneal junction
• 6) S – cornea stroma
• 7) EP – pigmented epithelium
• 8) PCR – pars cilliaris retinae
• 9) PIR – pars iridica retinae
• 12) Č – lens
• a) EC – lens epithelium
• b) VČ – lens fibers
• c) PČ – lens capsule
• 13) PN – pars nervosa retinae
• a) ZLM – outer limiting membrane
• b) ZJV – outer nuclear layer

---

Eye – HE, 21,6x

Eye:

• 1) A – artefact
• 3) NO – nervus opticus
• 7) EP – pigmented epithelium
• 11) CH – choroidea
• 13) PN – pars nervosa retinae
• g) VNV – nerve fibers layer

---

Eye – HE, 40x

Eye:

• 1) A – artefact
• 10) SK – vitreous body
• 13) PN – pars nervosa retinae
• a) ZLM – outer limiting membrane
• b) ZJV – outer nuclear layer
• c) ZPV – outer plexiform layer
• d) VJV – inner nuclear layer
• e) VPV – inner plexiform layer
• f) GV – ganglion layer
• g) VNV – nerve fibers layer
• h) VLM – inner limiting membrane

---
